FAULHABER launches GPT gearhead family up to 25 Nm torque

Key takeaway

• FAULHABER has launched a new family of planetary gearheads designed to deliver high torque in a compact form factor, with diameters from 14 to 42 mm and intermittent torques up to 25 Nm.

• The lineup includes low-noise variants that reduce noise by up to 10 dB for collaborative and multi-motor applications, as well as reinforced HT models for demanding environmental conditions.

• The gears integrate with FAULHABER's existing motor and drive ecosystem, allowing engineers to build matched drive systems without additional adapters.

3 Key Points

FAQ

How much noise reduction do the low-noise GPT gearheads offer compared to standard models?

The 22 GPT LN and 32 GPT LN reduce noise by up to 10 dB compared with the standard version, while still transmitting occasional peak torques of up to 4 and 12 Nm, respectively.

What torque and speed range does the largest GPT gearhead deliver?

The 42 GPT series can achieve intermittent torque of up to 25 Nm, with continuous torques between 6 and 18 Nm and speeds up to 24,000 rpm.

What is the operating temperature range for the new GPT gearheads?

Standard and low-noise variants operate from −30° to +110°C, while the HT models operate between −30° and +120°C.
